New GP-20D 3:1 Ratio Pump
The Complete Transfer Pump Solution!
Designed for Greater Reliability, Performance and Value in Material.
Features
- Easily detachable air motor.
- Single piston air powered drum pump
- New 3:1 ratio air motor for higher viscosity fluids
- Quick air motor changeover with exclusive IPM design
- Extremely robust pump packings
- Standard 55 gallon drum design
- Uniquely designed piston seals restrict corrosive material from remaining on the shaft. This feature is especially helpful with Isocyanates which tend to crystallize on the shaft after exposure to air
$1,650.00
Technical Information
Description : GP-20D
Pressure Ratio : 3:1
Max Output : 5.5 GPM (20 LPM)
Pump Stroke : 4 inches (101mm)
Air Inlet Pressure Range :
30~180 PSI (2~12 bar)
Max Fluid Output Pressure : 540 PSI (36 bar)
Air Inlet Size : 3/8″ NPT(F)
Fluid Outlet Port Size: 3/4″ NPT(F)
Typical Applications
- Foam/Polyurea coating chemical supply
- Spray gun supply
- Dispensing valve supply
- Fluid transfer
- Motor oil transfer
- Urethanes for wood products
- Coatings for fabricated metal components
- Varnishes
- Lacquers
- Lubricants
- Mold Release Agents
Typical Fluids Handled
- Solvent based paints
- Water based paints (SST model)
- Various solvents
- Solvents
- Chemical based cleaning supplies
- Chemicals
- Catalysts
- Isocyanates
- Adhesives
- Resins
- Polyurethanes
- Polyureas
